Monel K500 Bolts

Name: Monel K500 Bolts
Brand: Skyland Metal & Alloys Inc.
Price: 100.0 INR
Availability: InStock

Price 100.0 INR/ Kilograms

Get a Price/Quote

MOQ : 1 Kilograms

Monel K500 Bolts Specification

Hardness
Rockwell B90 - C34 (age hardened)

Width
Across Flats as per Standard Hex Dimensions

Grade
Monel K500

Temper
Annealed or Age Hardened

Purity
Nickel-Copper Alloy (Approx. Ni 63%, Cu 30%)

Surface
Bright, Smooth Finish

Standard
ASTM B865, ASME SB865, DIN, ISO, BS

Thickness
Varies as per diameter - Standard Bolt Sizes

Strength
Ultimate Tensile Strength: 965 MPa min. (age hardened)

Product Type
Bolts

Material
Monel K500

Alloy
Nickel-Copper Alloy with Aluminum and Titanium

Shape
Hex Bolt

Moisture
Corrosion Resistant

Chemical Composition
Nickel (Ni) 63.0%, Copper (Cu) 29.5%, Aluminum (Al) 2.30 - 3.15%, Titanium (Ti) 0.35 - 0.85%, Iron (Fe) 2.0% max, Manganese (Mn) 1.5% max, Carbon (C) 0.25% max

Application
Corrosive Environments, Seawater, Pump Shafts, Valves

Dimension (L*W*H)
Custom sizes (e.g., M6 x 20mm, M10 x 50mm, etc.)

Color
Metallic Silver

Finish Option
Plain, PTFE Coated, Zinc Plated (if specified)

Size Range
M3 to M36, 1/8" to 1-1/2" (Custom Sizes on Request)

Thread Type
Metric, UNC, UNF (Custom Threads available)

Density
8.44 g/cm3

Magnetic Permeability
Non-magnetic up to -200F

Melting Point
1315C

Manufacturing Process
Forged or Cold Formed

Packaging
Export Wooden Boxes, Cartons, as per customer requirement

Thread Direction
Right Hand (Standard), Left Hand (on request)

Operating Temperature
-150C to +600C

Corrosion Resistance
Excellent resistance to seawater, acids, alkaline environments

Head Type
Hexagonal

Monel K500 Bolts Trade Information

Minimum Order Quantity
1 Kilograms

Delivery Time
7 Days

Monel K500 Bolts About

Monel K500 bolts are standard fasteners made from a special nickel-copper alloy. These bolts have some features that are widely used in various applications where they are exposed to high stress levels. They are made to endure tough environments, and they are used where normal steel bolts would rust or break.

Unmatched Corrosion Resistance for Critical Environments

Monel K500 Bolts offer outstanding protection against seawater, acids, and alkaline conditions, making them the go-to solution for marine, offshore, and chemical industries. Their advanced nickel-copper alloy composition shields equipment and structures from corrosion, ensuring reliability and longevity even in the harshest of environments.

Precision Engineering & Customization Options

Available in Metric (M3-M36), UNC, UNF threads, and custom sizes, Monel K500 Bolts provide flexibility for diverse assembly requirements. Right-hand thread direction is standard, with left-hand and specialty threads available upon request. Finishing options, such as PTFE coating or zinc plating, further adapt the bolts to specific operational or aesthetic demands.

FAQ's of Monel K500 Bolts:

Q: How are Monel K500 Bolts manufactured to ensure strength and durability?

A: Monel K500 Bolts are produced using forged or cold-formed processes, followed by annealing or age hardening to reach a high tensile strength of at least 965 MPa. This method guarantees superior mechanical properties and longevity.

Q: What environments are Monel K500 Bolts best suited for?

A: These bolts excel in corrosive settings such as seawater, chemical processing, pump shafts, and valves, thanks to their excellent resistance to acids, alkalis, and marine environments.

Q: When should custom threads or sizes be requested for Monel K500 Bolts?

A: Custom threads (besides standard Metric, UNC, or UNF) and non-standard bolt sizes should be requested when your application requires unique fitting or when accommodating specialized equipment or assemblies.

Q: Where can Monel K500 Bolts be supplied and in what packaging options?

A: As a global exporter, importer, manufacturer, supplier, and trader, Monel K500 Bolts can be delivered worldwide. Packaging includes export-grade wooden boxes, cartons, or as per customer specifications to ensure safe delivery.

Q: What is the chemical composition of Monel K500 Bolts?

A: Monel K500 Bolts are composed of approximately 63% Nickel, 29.5% Copper, 2.30-3.15% Aluminum, 0.35-0.85% Titanium, with trace amounts of Iron, Manganese, and Carbon, providing their unique strength and corrosion resistance.

Q: How do finishing options like PTFE coating or zinc plating benefit Monel K500 Bolts?

A: Optional finishes such as PTFE coating or zinc plating add further protection against specific environmental hazards and can aid in lubrication, reduce galling, or meet visual and functional requirements.
