Super Duplex Steel S32760 Valves

Name: Super Duplex Steel S32760 Valves
Brand: Skyland Metal & Alloys Inc.
Price: 500.0 INR
Availability: InStock

Price 500.0 INR/ Kilograms

Get a Price/Quote

MOQ : 1 Kilograms

Super Duplex Steel S32760 Valves Specification

Heat Resistance
Yes

Temper
Solution Annealed

Diameter
1/2 NB to 24 NB or as per design

Corrosion Resistant
Excellent resistance to pitting, crevice and general corrosion

Material Composition %
Cr 24-26%, Ni 6-8%, Mo 3-5%, N 0.20-0.30%, Cu 0.5-1% approx.

Width
Customizable as per requirement

Chemical Composition
Cr 24-26%, Ni 6-8%, Mo 3-5%, N 0.20-0.30%, Mn, Si, Cu, Fe Balance

Recyclable
Yes

Coating Type
Uncoated, passivation for enhanced resistance

Hardness
Max. 290 HB

Product Form
Valve (Flanged End, Globe/Stop/Control)

Tensile Strength
Min. 800 MPa

Size
Customizable (Standard Sizes Available)

Product Name
Super Duplex Steel S32760 Valve

Steel Type
Super Duplex Stainless Steel

Steel Product Type
Manual & Automated Valves

Grade
S32760 (1.4501)

Thickness
Body thickness as per ANSI/ASME standard sizes

Shape
Valve (Flanged, Globe type)

Steel Standard
ASTM A182, UNS S32760

Surface
Shot blasted, passivated or polished finish

Composition
Super Duplex Stainless Steel Alloy

Application
Oil & Gas, Petrochemical, Desalination, Chemical Processing, Marine Engineering

Dimension (L*W*H)
As per standard and custom specifications

Weight
Varies as per size and design (from 2 kg to above 40 kg)

Color
Metallic Silver/Grey

Material Grade
S32760

Finish Type
Polished / Machined / Shot Blasted

Usage
Industrial flow control, isolation and regulation

Pressure Rating
Class 150#, 300#, 600#, up to 2500#

Design Standard
ASME B16.34, API 600, API 6D as applicable

Testing
Hydrostatic, Pneumatic, and NDT as per standard

Impact Toughness
Excellent (>50J at -46C)

Leakage Class
API 598, EN 12266-1

Operation Type
Manual, Gear Operated, Pneumatic, Electric Actuator

Service Life
Long service due to high durability and corrosion resistance

End Connection
Flanged, Butt Weld, Socket Weld, Screwed

Super Duplex Steel S32760 Valves Trade Information

Minimum Order Quantity
1 Kilograms

Delivery Time
7 Days

Super Duplex Steel S32760 Valves About

Super duplex steel S32760 valves have become increasingly popular due to their superior performance in various applications. This steel alloy comprises 25% chromium, 7% nickel, 4% molybdenum and 3% manganese, ensuring high strength and corrosion resistance in extreme environments. Combining these elements makes the material extremely durable and corrosion resistant even when exposed to saline water, caustic materials and organic acids for extended periods - making it perfect for several marine, oil and gas industry uses. Additionally, its excellent formability gives welders maximum freedom to manipulate the shape of the valve while ensuring sufficient strength and fluidity. No wonder super duplex steel s32760 valves are widely sought after!

Superior Corrosion and Heat Resistance

Fabricated from Super Duplex Stainless Steel S32760 alloy, these valves provide outstanding resistance to pitting, crevice, and general corrosion, even in aggressive environments. Their design ensures functional resilience up to 300C and maintains mechanical integrity under severe conditions commonly encountered in oil & gas, marine, and chemical industries.

Versatile End Connections and Operation Modes

These valves are available with flanged, screwed, or butt-weld end connections to seamlessly fit existing piping systems. Operation can be manual (handwheel), gear-operated, or actuator-assisted, offering enhanced flexibility for process automation and ease of use in varied industrial settings.

Comprehensive Compliance and Testing

Each valve is manufactured and rigorously tested in accordance with API 600, API 598, PED/97/23/EC, and NACE MR0175/ISO 15156 standards. All units undergo hydrostatic and pneumatic pressure testing and can be supplied with fire-safe designs and custom gaskets as per client requirements, assuring safety and regulatory compliance.

FAQ's of Super Duplex Steel S32760 Valves:

Q: How are Super Duplex Steel S32760 Valves tested for leakage and pressure resilience?

A: Each valve undergoes hydrostatic and pneumatic pressure testing according to international standards such as API 598 to ensure leak-tight sealing and robust performance under operating pressures ranging from Class 150# to 2500#.

Q: What industrial applications are these S32760 valves most suitable for?

A: Super Duplex S32760 valves are widely used in oil & gas, petrochemical, desalination, chemical processing, and marine engineering due to their excellent resistance to corrosion, high strength, and reliable flow control.

Q: When should a fire-safe design be considered for S32760 valves?

A: A fire-safe design is recommended for installations where there is a risk of fire exposure or where regulatory standards require it. This feature is available upon request for enhanced safety and compliance.

Q: Where can customized options such as sizing, face-to-face dimensions, and operation types be incorporated?

A: Valves can be tailored for specific project requirements, including custom sizes, widths, face-to-face dimensions per ASME B16.10, and various operational types (manual, gear, actuator), as per customer and application needs.

Q: What is the process for ordering and receiving these valves?

A: Order quantities and packaging depend on supplier policies. Each valve is typically shipped in export-standard wooden cases with bubble wrap, and minimum order requirements apply as per the supplier. Customization and compliance documentation can be provided on request.

Q: How do these valves benefit industrial flow control operations?

A: These valves provide high reliability, minimal leakage, and enduring performance in critical operations, protecting systems from corrosion and ensuring consistent isolation and regulation of industrial flows, reducing maintenance and operational downtime.
