Inconel 686 Bars

Name: Inconel 686 Bars
Brand: Skyland Metal & Alloys Inc.
Price: 500.0 INR
Availability: InStock

Get a Price/Quote

MOQ : 1 Kilograms

Inconel 686 Bars Specification

Grade
Inconel 686

Surface Treatment
Bright, Polished, Black, Peeled

Type
Bar/Rod

Material
Inconel 686 (Nickel-Chromium-Molybdenum Alloy)

Shape
Round Bar

Standard
ASTM B166, ASME SB166

Dimensions
Custom sizes, Diameter: 5mm to 500mm, Length: up to 6000mm

Tolerance
H8, H9, H10 or custom

Steel Type
Nickel Based Superalloy

Technics
Hot Rolled, Cold Drawn, Forged

Thickness
As per requirement

Application
Chemical Processing, Power Generation, Oil & Gas, Marine, Aerospace

Export Packaging
Standard seaworthy packing, wooden boxes/crates

Machinability
Good, but work hardens rapidly

Elongation
35% min

Density
8.5 g/cm3

Finish
Smooth finish, available in cut lengths

Melting Point
1338C - 1390C

Ultimate Tensile Strength
760 MPa min

Corrosion Resistance
Excellent resistance to general and localized corrosion, pitting, and crevice corrosion

Yield Strength (0.2% offset)
355 MPa min

Hardness
Rockwell B90 max

Inconel 686 Bars Trade Information

Minimum Order Quantity
1 Kilograms

Delivery Time
7 Days

Inconel 686 Bars About

Inconel 686 Bars are composed of a unique blend of metals, which includes nickel-chromium-molybdenum-tungsten and other elements such as copper, iron, and manganese. This combination of factors gives Inconel 686 Bars superior corrosion resistance, high-temperature strength, and relative ease of fabrication. Adding chromium to the alloy helps increase its resistance to pitting in almost all corrosive environments, while the molybdenum content enables it to remain strong at extreme temperatures. Tungsten is also added to give Inconel 686 Bars increased wear and abrasion resistance and enhanced fatigue properties. Each element contributes to the overall effectiveness of this distinct alloy.

Superior Corrosion Resistance

Inconel 686 Bars are engineered to withstand aggressive environments, exhibiting excellent resistance to general corrosion, as well as to pitting and crevice corrosion. This makes them ideal for critical applications in industries like oil & gas, marine, and chemical processing, where long-lasting performance and reliability are essential.

Precision and Versatility in Manufacturing

These bars are available in a variety of finishes-including bright, polished, black, and peeled-and support custom dimensions to suit diverse application requirements. Manufactured through hot rolling, cold drawing, or forging, Inconel 686 Bars meet rigorous international specifications and offer precision tolerances for superior quality.

FAQ's of Inconel 686 Bars:

Q: How are Inconel 686 Bars manufactured?

A: Inconel 686 Bars are produced using techniques such as hot rolling, cold drawing, or forging, depending on application specifications. The processes ensure optimal mechanical properties, dimensional accuracy, and surface finishes like bright, polished, black, or peeled.

Q: What industries commonly use Inconel 686 Bars and why?

A: These bars are widely used in chemical processing, power generation, oil & gas, marine, and aerospace sectors. Their appeal lies in exceptional corrosion resistance and strong mechanical characteristics, critical for demanding environments requiring longevity and structural integrity.

Q: When should Inconel 686 Bars be selected over other alloys?

A: Inconel 686 Bars are the preferred choice when high resistance to both general and localized corrosion, such as pitting and crevice attacks, is necessary. They are ideal for components exposed to aggressive chemicals, seawater, or high-temperature conditions.

Q: Where do custom sizing and packaging options apply?

A: Custom dimensions-such as diameter, thickness, and length up to 6000mm-are available for Inconel 686 Bars to meet specific project needs. For export, bars are securely packed in standard seaworthy packaging, typically using wooden crates or boxes to ensure safe delivery.

Q: What are the benefits of choosing Inconel 686 Bars for critical applications?

A: The primary benefits include excellent corrosion resistance, high tensile strength, good elongation for formability, and compliance with ASTM B166 and ASME SB166 standards. These traits ensure long service life and reliability in challenging environments.

Q: How is the machinability of Inconel 686 Bars managed?

A: While Inconel 686 offers good machinability, it work hardens rapidly. Proper tooling, slower speeds, and consistent cooling are recommended to achieve desired results while maintaining the bar's mechanical and corrosion-resistant properties.
