Monel 400 Plates

Name: Monel 400 Plates
Brand: Skyland Metal & Alloys Inc.
Price: 500.0 INR
Availability: InStock

Price 500.0 INR/ Kilograms

Get a Price/Quote

MOQ : 1 Kilograms

Monel 400 Plates Specification

Hardness
60-85 HRB

Grade
Monel 400

Thickness
0.5 mm to 50 mm

Strength
Ultimate Tensile Strength: 480 MPa minimum

Standard
ASTM B127, ASME SB127

Width
Up to 2000 mm

Purity
99% minimum

Surface
Bright, Polished, Hot Rolled, Cold Rolled

Temper
Soft, Hard, Half Hard (Available on request)

Product Type
Plates

Material
Monel 400

Alloy
Nickel-Copper Alloy

Shape
Plate

Moisture
Nil

Chemical Composition
Ni 63% min, Cu 28-34%, Fe 2.5% max, Mn 2% max, S 0.024% max, Si 0.5% max, C 0.3% max

Application
Oil & Gas, Power Generation, Petrochemical, Aerospace

Dimension (L*W*H)
Customized, Standard: 2000 mm x 1000 mm x (0.5-50 mm)

Color
Silvery Grey

Finish
2B, BA, No. 1, No. 4, Mirror Finish

Packaging
Wooden Cases, Pallet Packing, Bubble Wrap

Thermal Conductivity
22.3 W/mK

Edge Type
Mill, Sheared, Slit, Round

Melting Point
1300C - 1350C

Density
8.80 g/cm3

Yield Strength (0.2% offset)
170 MPa minimum

Corrosion Resistance
Excellent in seawater and alkaline environments

Elongation
35% minimum

Monel 400 Plates Trade Information

Minimum Order Quantity
1 Kilograms

Delivery Time
7 Days

Monel 400 Plates About

Monel 400 plates are flat-rolled nickel-copper alloy products manufactured from UNS N04400, also referenced as Alloy 400 or Werkstoff 2.4360. The material is composed mainly of nickel (6370%) and copper (2834%), with small additions of iron, manganese, and other elements. This combination gives the alloy solid mechanical strength, good ductility, and notably good resistance to corrosion in both seawater and reducing acid environments. The material holds up well in hydrofluoric acid and hot sulphuric acid conditions where many other grades would fail. Monel 400 plates are regularly used in marine hardware, chemical processing equipment, heat exchangers, oil refinery components, and water treatment systems.

Versatile Mechanical Strength

Monel 400 Plates provide an ultimate tensile strength of at least 480 MPa and a yield strength of 170 MPa minimum, ensuring they can withstand demanding operational environments. Their notable elongation of 35% or more delivers excellent fabrication properties, maintaining structural integrity under stress.

Exceptional Corrosion Resistance

These plates are engineered to resist corrosion superbly, even in marine and alkaline settings. Monel 400's composition makes it the material of choice for industries exposed to aggressive substances, supporting long-lasting service and minimal maintenance.

Comprehensive Customization Options

Available in thicknesses ranging from 0.5 mm to 50 mm and widths up to 2000 mm, Monel 400 Plates can be tailored to precise requirements. A variety of finishes and edge types further enable adaptation for different technical and aesthetic needs.

FAQ's of Monel 400 Plates:

Q: How are Monel 400 Plates commonly used in industrial applications?

A: Monel 400 Plates are primarily used in industries such as oil & gas, power generation, petrochemical, and aerospace, where their corrosion resistance, high strength, and durability are crucial for equipment like heat exchangers, valves, pumps, and marine components.

Q: What makes Monel 400 Plates highly resistant to corrosion?

A: The high nickel (minimum 63%) and copper (28-34%) content in Monel 400 Plates provides outstanding resistance to seawater, alkaline environments, and many acids, ensuring reliable performance even in aggressive and corrosive settings.

Q: When should I choose a specific edge type or finish for my Monel 400 Plate order?

A: Edge types (mill, sheared, slit, round) and finishes (2B, BA, No. 1, No. 4, mirror) are selected based on your application's specific requirements, such as fitting compatibility, appearance, or surface roughness needed for further processing or installation.

Q: Where are Monel 400 Plates manufactured and supplied?

A: Monel 400 Plates are produced and exported worldwide by certified manufacturers and suppliers, meeting the standards of ASTM B127 and ASME SB127, and are packaged securely in wooden cases, on pallets, or with bubble wrap to ensure safe delivery.

Q: What is the process for customizing the dimensions of Monel 400 Plates?

A: Customization involves selecting the desired thickness (0.5 mm to 50 mm), width (up to 2000 mm), length, edge type, and finish. These specifications can be discussed with the manufacturer or supplier during the ordering process to meet your unique requirements.

Q: What are the key benefits of using Monel 400 Plates over standard stainless steel plates?

A: Monel 400 Plates offer superior corrosion resistance in harsh environments, greater durability, excellent mechanical properties, and reliable thermal conductivity, making them more suitable for challenging industrial applications than many standard stainless steel options.
