Monel 400 Tubing

Name: Monel 400 Tubing
Brand: Skyland Metal & Alloys Inc.
Price: 500.0 INR
Availability: InStock

Price 500.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Kilograms

Monel 400 Tubing Specification

Thickness
0.5 mm to 15 mm

Grade
Monel 400

Purity
99.9%

Standard
ASTM B165, ASME SB165

Width
As per requirement

Hardness
70-90 HRB (Rockwell B)

Strength
Ultimate Tensile Strength: 550 MPa min

Temper
Annealed / Soft

Surface
Bright, Polished, Annealed

Product Type
Tubing / Tube / Pipe

Material
Monel 400

Alloy
Nickel-Copper Alloy

Shape
Round, Square, Rectangular Tubing

Moisture
Nil / Dry

Chemical Composition
Ni: 63.0% min, Cu: 28-34%, Fe: 2.5% max, Mn: 2.0% max, Si: 0.5% max, C: 0.3% max, S: 0.024% max

Application
Corrosive Environments, Seawater, Chemical Equipments

Dimension (L*W*H)
Custom / As specified by client

Color
Silver / Metallic Grey

Elongation
35% min

Length
Up to 12 meters or as customized

Workability
Excellent machinability and weldability

Finish
Seamless / Welded

Density
8.80 g/cm3

Pressure Rating
Suitable for high pressure applications

Wall Thickness
0.5 mm to 15 mm

Melting Point
1300C - 1350C

Outer Diameter
6 mm to 219 mm

Export Packaging
Standard export worthy wooden boxes/crates

Yield Strength (0.2% Offset)
170 MPa min

Corrosion Resistance
Outstanding resistance to seawater, acids, alkalis

Monel 400 Tubing Trade Information

Minimum Order Quantity
1 Kilograms

Delivery Time
7 Days

Monel 400 Tubing About

Monel 400 tubing is one of the most used and highly resistant tubing. Because of its characteristics in different environments, this tubing is used in different applications. It is primarily made from nickel and copper and has additions of iron, manganese, silicon and carbon, making it mechanically very strong.

Monel 400 Tubing: Superior Strength and Versatility

Manufactured from premium nickel-copper alloy, Monel 400 Tubing is highly valued for its unique combination of strength, ductility, and unbeatable corrosion resistance. Designed to withstand harsh environments, it excels in marine, chemical, and industrial applications. Its seamless and welded options, wide range of diameters and wall thicknesses, along with custom lengths, ensure that clients receive tailored solutions to meet exact specifications. The material's excellent machinability and weldability further enhance its adaptability during installation and use.

Advanced Manufacturing and Stringent Standards

Monel 400 Tubing is produced according to strict ASTM B165 and ASME SB165 standards, ensuring consistent quality and performance. Each tube is meticulously annealed, polished, and inspected for adherence to critical dimensions and mechanical properties. Export packaging meets international safety requirements, safeguarding products during transit. The chemical composition is tightly controlled, guaranteeing superior purity and alloy uniformity. These tubes are supplied to global markets by leading exporters, manufacturers, and suppliers, supported by expert technical teams.

FAQ's of Monel 400 Tubing:

Q: How is Monel 400 Tubing typically used in industrial applications?

A: Monel 400 Tubing is widely used in demanding environments requiring robust corrosion resistance, such as seawater desalination plants, chemical processing equipment, and marine systems. Its durability allows it to perform reliably under high pressure and in corrosive conditions, making it suitable for oil & gas, heat exchangers, and shipbuilding industries.

Q: What makes Monel 400 Tubing suitable for high-pressure environments?

A: Monel 400 Tubing offers a minimum yield strength of 170 MPa and an ultimate tensile strength of 550 MPa, making it exceptionally strong and able to maintain integrity under high-pressure applications. Its seamless construction further enhances its pressure-holding capabilities and safety.

Q: When should I choose seamless versus welded Monel 400 Tubing?

A: Seamless Monel 400 Tubing is ideal when absolute reliability, high pressure, and superior corrosion resistance are required. Welded variants are suitable for lower pressure applications or where cost-efficiency for longer lengths is a priority. The selection depends on the specific demands of your project and operating environment.

Q: Where can customized Monel 400 Tubing dimensions be arranged?

A: Customized dimensions, including unique diameters, lengths, and thicknesses, can be arranged directly with reputable manufacturers, suppliers, or exporters. Most offer tubing tailored to client specifications, ensuring compatibility with specialized installations or equipment.

Q: What processes are used to ensure Monel 400 Tubing's quality and finish?

A: Monel 400 Tubing undergoes annealing, bright polishing, and precise dimensioning. Products are inspected for mechanical and chemical characteristics conforming to ASTM B165 and ASME SB165 standards. Export packaging in wooden crates ensures the tubing arrives undamaged and moisture-free at its destination.

Q: What are the key benefits of using Monel 400 Tubing in corrosive environments?

A: Monel 400's outstanding resistance to acids, alkalis, and seawater significantly extends the service life of equipment, reduces maintenance costs, and enhances operational safety even in harsh settings. Its high purity and carefully controlled composition ensure predictable, dependable performance.
